3M Products & Supplies

3M™ Scotch-Weld™ Composite Surfacing Film AF 325M, Blue, .035 wt, 36 in x 36 yd, 1 Roll/Case - 7000046466

SKU: 7000046466
MPN: 7000046466
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00021200233333
3M ID: 62338253057
$8,145.89 each
Hurry up! Current stock:

Product Description

3M™ Scotch-Weld™ Composite Surfacing Film AF 325 M, Blue is a thermosetting epoxy that we developed as an excellent product for surfacing composites, where its smooth, void-free surface with minimal pinholes reduces the need for subsequent surface fill or finishing and pre-paint prep.

Features

  • Excellent for surfacing composite parts
  • Reduces the need for subsequent surface filling, fairing and sanding operations
  • Provides a smooth surface with minimal pinholes and other surface imperfections
  • Low density formulation aids in pre-paint surface preparation
  • Co-cure compatible with most epoxy composite prepreg systems
  • Available in both white and blue to provide color contrast to underlying composite prepreg
Spec Sheet



Downloads

Specifications

Shelf Life730
Product UsageAircraft Components; Aircraft Engine Components; Composite Materials; Helicopter Components
Overall Width (Imperial) UOMin
Overall Width (Metric) UOMm
Maximum Operating Temperature (Celsius) UOMDegree
Adhesive TypeEpoxy
Overall Width (Imperial)36.0
Minimum Operating Temperature (Fahrenheit)-67.0
Product FormRoll
Maximum Cure Conditions (Fahrenheit)350.0
Maximum Operating Temperature (Fahrenheit)300.0
Minimum Operating Temperature (Celsius)-55.0
Minimum Cure Conditions (Fahrenheit)250.0
Product ColorBlue
ApplicationComposite Surfacing
Minimum Cure Conditions (Celsius)121.0
Maximum Cure Conditions (Celsius)177.0
Overall Length (Imperial)36.0
Overall Length (Metric)33.0
Overall Width (Metric)0.9
Overall Length (Imperial) UOMyd
Nominal Weight (Imperial)0.035
Maximum Operating Temperature (Fahrenheit) UOMDegree
Minimum Operating Temperature (Celsius) UOMDegree
Maximum Operating Temperature (Celsius)149.0
Overall Length (Metric) UOMm
Country of OriginUnited States
Minimum Operating Temperature (Fahrenheit) UOMDegree
